The Managed GigEthos Lite Ethernet switch on a dark hangar floor, with a small fixed-wing UAV out of focus behind it

World's Smallest
7 Port Managed Switch

Managed GigEthos Lite. Gigabit Ethernet and a serial console port for direct command-line configuration and monitoring.

From $595.00
In stock
ICD Drawing (PDF)
Size
73.3 × 50.8 × 8.3 mm
2.9″ × 2.0″
Weight
26 g
Power
0 to 7 ports in use
3.4 to 4.6 W
Input voltage
4.5 to 42 V
Trusted by Industry Leaders
L3HarrisScientific SystemsSRI InternationalFortem TechnologiesNear Earth AutonomyCollins AerospaceJohns Hopkins Applied Physics LaboratoryGeorgia TechBAE SystemsLockheed Martin

We offer the Smallest Ethernet Switches for Your Unique Applications.

The three switches are top views drawn at one scale. The dashed outline is a standard credit card.

Compare Specs

Shop Our Products

Swipe sideways to compare all three.

NEW!World's Smallest 7 Port Managed Switch

Managed GigEthos Lite

5 Port 100 Mb Switch

Ethos Lite

5 Port Gigabit Switch

GigEthos Lite
Size
2.9″ × 2.0″
73.3 × 50.8 mm
1.75″ × 1.75″
44.5 × 44.5 mm
2.9″ × 1.9″
73.3 × 48.2 mm
Height
0.328″
8.3 mm
0.424″
10.8 mm
0.328″
8.3 mm
Weight
26 g
15 g
25 g
Power Min/Max
3.4 to 4.6 W
0 to 7 ports in use
0.5 to 1.75 W
0 to 5 ports in use
0.5 to 3.8 W
0 to 5 ports in use
Voltage Input Range
4.5 to 42 V
5 to 15 V
4.5 to 42 V
Ethernet
10/100/1000 Mbps
10/100 Mbps
10/100/1000 Mbps
Ports
7, plus 5-pin serial header
5
5
Switch Type
Managed
VLAN tagging, QoS traffic prioritization, port mirroring
Unmanaged
Unmanaged
Part Number
ACS-ETH2-10
ACS-ETH0-13
ACS-ETH1-11
DocumentsICD Drawing (PDF)Firmware Source CodeICD Drawing (PDF)3D Step File (ZIP)ICD Drawing (PDF)3D Step File (ZIP)
Cable Kit
+$20
7 RJ45 pigtails, 1 power pigtail
+$20
5 RJ45 pigtails, 1 power pigtail
+$25
5 RJ45 pigtails, 1 power pigtail
Conformal Coat
+$35
+$35
+$35
Price

From$595.00

View product

From$295.00

View product

From$445.00

View product
Common to all three
Operating Temperature
-40° to +60°C
Storage Temperature
-45° to +85°C
Connectors
Molex PicoBlade
Topology
Daisy-chain or star

All of our ethernet switches are manufactured in the USA in a facility that is compliant with the AS9100 Aerospace Management System.

A small fixed-wing UAV in flight at dusk above snow-dusted mountains

About us

We're a team of electrical engineers making the small, purpose-built parts we wish already existed for UAV and aerospace teams.

Ethos Lite started as a custom switch for an aerospace project with tight Size, Weight and Power (SWaP) limits. We needed several network devices on a UAV to share one data link, and nothing on the market was small, light and rugged enough, so we built our own.

10/100 Mb was plenty, since UAV radio links usually top out in the tens of Mbit/s. Knowing how hard that switch had been to find, we turned it into a commercial product: Ethos Lite.

Gadgetsmyth LLC
Orem, UT
Contact us
Made in the USA

Made in the USA with Aerospace-Grade Quality

All of our ethernet switches are manufactured in the USA in a facility that is compliant with the AS9100 Aerospace Management System.

A pick-and-place machine placing a component on a panel of circuit boards
A small fixed-wing UAV on a wet runway at night

So we built
our own.

Contact us

We’re here to help! If you have any needs or questions feel free to reach out.

Gadgetsmyth LLC
1201 N 800 E
Orem, UT 84097
